Loctite 222

LOC003

LOCTITE® 222 is a low-strength threadlocker ideal for small fasteners (under 6.35 mm or 1/4" in diameter). It prevents loosening from shock and vibration and is easily removable with hand tools. Suitable for low-strength metals like aluminum and brass, it's perfect for adjustment screws, countersunk head screws, and set screws.

Ideal for low-strength threadlocking of adjustment screws, countersunk head screws and set screws
Prevents fastener loosening on vibrating assemblies, e.g. pumps, gear boxes, presses
Ideal for small thread sizes up to 6.35 mm (1/4")
Can be disassembled with ordinary hand tools for easy service and maintenance

Product Description

Loctite 222
Agency approvals / certificates / specifications, Regional approval for Europe only	NSF P1 Reg. No 123002
Application method	Dispense system, Manual
Application temperature	-55.0 - 150.0 °C (-65.0 - 300.0 °F )
Applications	Threadlocking
Breakaway torque, M10 Steel Nuts/Bolts	6.0 N·m (50.0 in./lb. )
Color	Purple
Cure Type	Anaerobic cure
Fixture time	20.0 min.
Key characteristics	Disassembly: removable, Fluorescent, General purpose, Mix: no mix required, Strength: low Strength, Thixotropic
Physical form	Liquid
Prevail torque, M10 Steel Nuts/Bolts	4.0 N·m (35.0 in./lb. )
Recommended for use with	Metal, Metal: passive metal
Viscosity, Speed 20 RPM	1200.0 mPa·s (cP)
